Electric Stackers
Electric Stackers
Electric Stackers
High quality portable lifters designed for industrial and manufacturing environments.
The electric stacker models offer a variety of maneuvering and handling capabilities. The units can be equipped with a variety of options to handle products and pallets. Featuring top quality construction, these units have been engineered with durability, ease of use and safety in mind. The masts are designed to maximize view of the forks during operation making it easy for operators to maneuver safely. The MOSFET control technology makes control reaction time extremely fast which makes controlling the unit safe and more accurate. And, the regenerative braking system feeds energy generated during braking/stopping back into charging the battery. This means your equipment is running for longer periods of time without downtime for recharging.
4-Way Multi-Directional Stacker Truck
Available in standard models and easily customized, the 4 VIE Electric Stacker is the multi-directional 4-way lift truck that offers the most specific solution for moving long pieces (bundles of bars, pipes, sections, etc.) inside narrow corridors and aisles.
With the 4 VIE, the operator simply sets the lift truck to the desired direction, forward, reverse, left or right, and is able to store or pick up very bulky loads. The multi-directional drive abilities makes it an ideal electric stacker for maneuvering in narrow aisles in warehouses and production lines.
4VIE – Stacker |
Specification |
Max Lifting Weight |
4,409 lbs (2000 kg) |
Vertical Lift Capacity |
11.5 ft (3500 mm) |
Operating Voltage |
24 VDC |
Master Electric Stacker
Maneuverable and ergonomic but, at the same time, solid and reliable, MASTER LIGHT and MASTER PLUS electric stacker trucks offer the ideal balance between power and agility in reduced spaces.
While MASTER LIGHT electric stacker can be used to move medium-heavy loads up to heights of 9.5 ft (2.9 meters), the MASTER PLUS electric stacker models have an even more robust structure with the ability to lift heavier loads up to heights of 11.5 ft (3.5 meters).
Master – Stacker |
Specification |
Max Lifting Weight |
2,645 lbs (1200 kg) |
Vertical Lift Capacity |
11.5 ft (3500 mm) |
Operating Voltage |
24 VDC |
Delta Electric Stacker
DELTA is the most concrete electric stacker within the handling industry offering power, ergonomics and safety and serves as the ideal solution for intense workloads involving the movement of goods on pallets in medium-sized/large environments.
Designed and manufactured to ensure excellent performance even at elevated heights, DELTA is able to offer high residual capacities up to heights of 11.5 ft (3.5 meters).
Delta – Stacker |
Specification |
Max Lifting Weight |
2,645 lbs (1200 kg) |
Vertical Lift Capacity |
11.5 ft (3500 mm) |
Operating Voltage |
24 VDC |
Delta TRX Triple Masted Electric Stacker
Delta TRX Triple Masted Electric Stacker features a three stage mast that allows for very high lifting of pallets and materials and still allows the contraction of the mast to meet normal clearance heights in doorways and corridors. The structure and materials used provide excellent performance and total safety when lifting loads to up to 14.5 ft (4.5 meters) from the ground.
Delta TXR- Stacker |
Specification |
Max Lifting Weight |
2,645 lbs (1200 kg) |
Vertical Lift Capacity |
14.75 ft (4500 mm) |
Operating Voltage |
24 VDC |
